EM-X11G

Fully Rugged Notebook
  • Support for Windows 10 system
  • Integrated 3G/4G all network communication, WiFi, Bluetooth and other communication modes
  • 5000mAh battery, 5.5 hours of machine endurance
  • IP65 high protection level, in accordance with MIL-STD-810G
  • Equipped with front 2 million and rear 8 million pixel camera
  • Support 1920×1080 FHD, optional with Corning gorilla screen and sunshine visual screen
  • Support 2D, Fingerprint and other functional modules for free selection

Description

Basic Parameters

Dimension 305 x 205 x 18mm
Weight device unit 3140g
Device Color black
LCD 11.6″ FHD 16:9, 1920*1080
Touch Panel 10 points capacitive, G+G, Corning Gorilla Glass
Camera Front 2.0MP Rear 8.0MP
I/O HDMI C x 1, GPS_SMA x 1,
USB 2.0 x 2, USB 3.0 x 1,
SIM Card x 1, TF Card x 1,
DB9 (RS232, RS485) x 2, RJ45 x 1,
Φ3.5mm standard earphone jack x 1
DC 12V 4A x 1
Power AC100V ~ 240V, 50Hz/60Hz output DC 12V/4A
GPS NA

Performance parameter

CPU Intel® GeminiLake N4100
OS Windows 10
RAM 4GB/8GB
ROM 128GB/256GB

Battery

Capacity 7.4V/5000mAh
Type Li_polyment, removeable battery
Endurance 5.5hrs ( 50% volume sounds, 200 nits brightness,
1080P HD video display by default )

Network connections

WIFI 2.4G+5.8G dual frequency, WIFI 802.11(a/b/g/n/ac)
Bluetooth BT4.2 (BLE) class1 transmission distance:10m
3G/4G LTE FDD: B1/B3/B5/B7/B8/B20/B28A
LTE TDD: B38/B40/B41
WCDMA: B1/B2/B5/B8
GSM: 850/900/1800/1900MHz

Reliability

Operation Temperature -10 °C ~ 50 °C
Storage Temperature -30 °C ~ 70 °C
Humidity 95% Non-Condensing
IP Grade IP65

Optional modules

2D Honeywell N3680
Optical Position: 5mil,Scan speed: 50 times/s
Fingerprint 070-Hello sensor
FPC1020 sensor
Fingerprint acquisition area:10mm x10mm
Resolution:192x192pixel/508DPI
