GP-1324D

Direct Thermal Label Printer

This label printer is designed as barcode label printer. It is simple, easy to configure and supports all Windows OS and standard equipped with USB port, It features printing speed up to 203mm/sec, perfect to use in retail , logistic and courier industry environments.

  • 203 dpi printing resolution
  • Fast printing speed up to 8 inch/second
  • Support QR barcode
  • Support Thermal paper, Thermal label, Adhesive thermal paper etc.

Description

Specification

Print Method Direct Thermal
Print Width Max. 104mm (4.09″)
Print Length Max. 2286mm (90″)
Print Speed 2 ~ 8 inch per second, Max. 203mm per sec
Print Resolution 203 dpi
Interface USB (Standard), USB+Bluetooth (Optional), USB +WIFI (Optional)
Memory 4M Flash, 8M SDRAM
Media Sensor Reflective and Transmissive Sensors (adjustable)
Media Type Continuous, gap, die-cut, fan-fold, black mark and others
Media Roll OD 130mm (5″)
Media Thickness Min. 0.06 (2.36mil) ~ Max. 0.254mm (10mil)
Media Width Min. 40mm (1.56”) ~ Max. 120mm (4.72”)
Media Roll Core Size Max. 38mm (1.5”), Min. 25.4mm (1”)
Media Gap Min. 2mm
Media Rolling Up Method Printing side outward rolling
Graphic Processing Support BMP/PCX/BAS files
1D Barcode Code39, Code93, Code128 subsets A, B, C, Codabar, Interleaved 2 of 5, EAN-13, EAN-14, Ean-128, UPC-A, UPC-E, EAN and UPC 2(5) digits add-on, MSI, PLESSEY, POSTNET, China POS, ITF14
2D Barcode QR Code
Humidity 25%~85%RH (operating); 10%~90%RH (storage)
Temperature 5ºC to 45ºC (operating); -10ºC to 50ºC (storage)

Power and Dimensions

Power Supply Input: AC 110V/240V
Output: DC24V/2.5A, 60W
Dimensions 285mm (W) x 210mm (D) x 180mm (H)
