TP-D825

Thermal Receipt Printer
  • Integrated board, higher reliability, more durable
  • Support GB18030 Font, multiple International Languages
  • Rich communication interface intelligent voice prompt, simple operation
  • Support network printing status monitoring, computer multi-connection printing
  • Embedded web page, directly through the IE to configure the printer

Description

Physical Parameter

Print Speed 250mm/s
Print Roll 79.5  ±0.5 mm
Dot Density 576 dots/line; 512 dots/line
Character size ANK Font, Font A : 12x24dots
Font B : 9X17 mm (9×17 dots)
Simplified/Traditional Chinese : 24x24dots
Font Standard GB18030
Print Command Compatible with ESC/POS emulation
Interface USB+Ethernet or
USB+Ethernet+Bluetooth or
USB+Ethernet+Bluetooth+Audio or
USB+Ethernet+WiIFI
Reliability 150km
Barcode Type UPC-A/UPC-E/JAN13 (EAN13) /JAN8 (EAN8)/ITF/CODABAR/CODE39/CODE93/CODE128
Paper Thickness 0.06~0.08mm
Input Buffer 800KB~1MB
NV Flash 256KB
Adapter outside
Adapter output AC 110V/220V, 50~60Hz
Adapter input DC 24V/2.5A
Printer input DC 24V/2.5A
Cashdrawer output DC 24V/1A
Work Environment 5ºC to 45ºC (temperature); 10ºC to 80ºC (humidity)
Storage Environment -10ºC to 50ºC (temperature); 10ºC to 90ºC (humidity)
Dimensions 204(W)*147(D)*138(H)mm
