BC-603

Two-dimensional image barcode scanner

Multi-Purpose for Everyday Use

  • Interface USB HID Keyboard
  • Resolution 648 x 480 pixels
  • To read 1D and 2D barcode
  • Auto Scanning Stand

Description

Electrical Characteristics

Interface USB HID Keyboard
Voltage 5VDC±5%
Current Consumption Max : 180mA

Optical Characteristics

Photo sensor CMOS array sensor
Sensor Resolution 648 x 480 pixels
Light source 5600K white LED
Aim light source Red Bar LED

Performance Characteristics

Decode angle Pitch angle: ±55°
Skew angle: ±55°
Tilt angle: ±180°
Min resolution 1D: 5mil
2D: 9mil
Min PCS value 30% UPC/EAN 13 (13mil)
Field of View 40° (H) x 30° (V)
Identification 1D: UPC-A, UPC-E, EAN-8, EAN-13, Code 39, Code 128, Interleaved 2 of 5, Codabar, Code93
2D: PDF417, MicroPDF417, Data Matrix, QR Code, Micro QR, Aztec

Physical Characteristics

Dimensions 70mm*95mm*168mm (L*W*H)
Weight 118g

Environmental Characteristics

Temp Operation: 0° to 50°C / 32° to 122°F
Storage: -40° to 80°C / -40° to 176°F
Humidity Operation: 5 – 95%
Storage: 5 – 95%
Drop Test 1.5m drop onto concrete surface
Ambient Light fluorescent light 4000 lx max, direct sun light 80,000 lx max, white light 4000 lx max

Depth of field

Symbology
5mil code39
UPCA 13mil
Min depth of field                       Max depth of field
30mm                                              80mm
50mm                                              210mm
