C-168/300s

Barcode Label Printer
  • Both reflective & transmissive sensors promote great flexibility to print on most types of labels including continuous, labels with gaps, labels with marks and even labels with holes.
  • The Free External Media stand easily increases the media capacity fourfold, saving you time on changing the media, which greatly enhances the efficiency.
  • All rotating parts are supported by ball bearings or fixed bearings, thereby eliminating wear caused from direct contact with plastic.
  • C168 is manufactured with the Industrial Class Stepping Motor used on our commercial models, ensuring strong power and stable performance.

Description

Specification

Model C168/300s
Printing method Direct Thermal & Thermal Transfer
Printing Resolution 300 dpi
Max printing speed 4 ips (101.6 mm/s)
Max printing width 4.17’ (106 mm)
Max printing length 79“ (4000 mm)
HEAT™ Level I
Memory 8 MB FLASH ROM, 16 MB SDRAM
Media Width: 4.37″(111 mm) max., 0.98″(25 mm) min.
OD: 4″(102 mm) max. or 9″(229 mm) max. (Using External Media Stand).
ID: 1″(25.4 mm) min.
Media Thickness 0.003″~ 0.006″(0.08 ~ 0.15 mm), including liner
Ribbon Wax, Wax/Resin, Resin
Ribbon roll: OD 3″(76.2 mm) max., ID 1″(25.4 mm) min.
Width: 4.33″(110 mm) max.; Length: 984′ (300 m) max.
Fonts Five built-in dot matrix ASCII fonts, user-downloadable TrueType Fonts
BarCode Types 1D Barcode: Code 39, Code 93, Code 128/ subset A,B,C, Codabar,
Interleave 2 of 5, UPC A/E 2 and 5 add-on, EAN-13/8/128, UCC-128, etc.
2D Barcode: MaxiCode, PDF417, Data matrix, QR Code
Media Sensor Reflective (Adjustable) / Transmissive (Two positions)
Interfaces RS-232 Serial, USB DEVICE 2.0
Power Adaptor Input: AC 100~240 V, 50~60 Hz; Output: DC 24 V, 2.5 A
Weight 6.17 lbs (2.8 kgs)
Dimensions W 9.3″(236mm) x D 11.5″(291mm) x H 7.8″(199 mm)
Optional Items Centronics Parallel Port (Factory dependent) Wi-Fi, Bluetooth, Guillotine Cutter, Rotary Cutter, External Label Rewinder, Media Guide Adapter, 10/100 M Adaptive Ethernet Port

Interface

CPU / Memory 32-bit ARM Processor / 2 MB FLASH ROM, 8 MB SDRAM
Media Roll-feed, die-cut, continuous, fan-fold, tags, tickets (plain paper or thermal paper)
Width: 4.33″ (110 mm) max., 98″ (25 mm) min.
Supply roll: OD 4″ (102 mm) max., ID 1“ (25.4 mm) min.
Thickness: 0.003’ ~ 0.007“ (0.08 ~ 0.18 mm), including liner
Ribbon Wax, Wax/Resin, Resin
Ribbon roll: OD 3’ (76.2 mm) max., ID 1″ (25.4 mm) core
Max width: 4.33“ (110 mm); Max length: 1181.10’ (360 m). Ink side: Out
Fonts Five built-in ASCII fonts; Optional multiple language fonts
Bar Code Types 1D Barcode: Code 39, Code 93, Code 128/subset A, B, C, Codabar, Interleave 2 of 5, UPC A/E 2 and 5 add-on, EAN-13/8/128, UCC-128.
2D Barcode: MaxiCode, PDF417, Data Matrix, QR.
Media sensor Reflective (Adjustable)
Interfaces RS-232 Serial, USB
Power rating 24 VDC power adapter
Weights 6.17 lbs (2.8 kgs)
Dimensions W 9.3 x D 11.4 x H 7.8 inches (W 236 x D 291 x H 199 mm)

Environment

Operating Temperature Temperature: 32° F – +104° F (0° C – 40° C)
Relative humidity: 5% – 85% non condensing
Storage Temperature Temperature: -40° F – +140° F (-40° C – 60° C)
Relative humidity: 5% – 85% non condensing
Optional items Cutter kit, Peeler Kit
