PL-330H

Thermal Receipt Printer

Fast, Reliable and Easy To Configure

The PL-330HUSE is the leading designed POS thermal receipt printer. It is fast, reliable, easy to configure and supports all the leading operating systems. It features fast printing up to 300mm/second, trusted reliability on the ceramic cutter, is perfect for use in retail, restaurant, kitchen, office or bank environments.

  • Reliable Japanese Thermal Print Head
  • Long-life Ceramic Auto-Cutter
  • Support Apple AirPrint and Google Print
  • Reprint Missing Printout
  • Support Cloud Printing
  • Support iOS, Android, Windows, Linux & OPOS

Description

Specification

Print Method Thermal line printing
Print Speed Max. 300mm/second
Paper Eject Direction Front
Paper Specification 79.5±0.5mm (width), 0.065~0.14mm (thickness), Max. 83mm (roll diameter)
Input Buffer 4 MB
Barcode Type UPC-A /UPC-E /EAN13 /EAN8 /CODE39 /ITF-25 /CODEBAR /CODE128 /PDF417/QR Code
Control Command ESC/POS Emulation, compatible with STAR line model printing commands
Character Set ASCII : 13 international character sets
Character printing command Support ANK character, user-defined characters and enlarged printing of Chinese characters 1~8 times, can adjust character line spacing
Print Head Life 150km*
Cutter Life 1.5 million cuts
Weight 1.45kg
Operating temperature 0ºC to 45ºC (operating); -10ºC to 40ºC (storage)

Electrical

Power Input DC 24V/2.5A
Power Supply Input AC 110V/240V, 50-60Hz
Cash Drawer Input RJ-11, DC 24V/1A
