TCP-M156

All-in-One POS Terminal

Reliable and Flexible

The TCP-M156 is an ergonomic design POS Terminal. The low power consumption CPU with reliable and durable architecture design to provide better POS solution on the market. Quick access to the hard drive disk to help you reducing your service cost and time. This terminal can matched your desire of high value POS solution.

  • Low-power consumption CPU, reliability and flexibility POS Terminal
  • Various peripherals – VFD, Second Display and MSR

Description

Specification

CPU Intel Celeron J1900 (2.0 GHz) quad-core processor i5-4210U dual-core 1.7GHz
Colour Black
Memory 4GB DDR3
Storage M100-128GB Dual Channel (SATA 3 Gbps x 1 + mSATA(3) x1)
Main Board Baytrail mother board
Display 15.6” TFT touch screen
Touch Panel 10 points capacitive touch panel
Resolution 1366 x 768
Operating System Windows 7 / 8 / 10 / IoT 10

I/O Ports

USB 2.0 6 4
Serial Port 5
LAN Port 1 1
Ethernet Realek PCI-E NIC RTL 8111E for 1000M bps
Audio Port 1 1
Audio Realtek ALC662 5.1 Channel HDA Codec , Support MIC/Line-out Ports 1* Amplifier
VGA 1
HDMI 1

Peripheral

Optional Build-in Peripheral MSR, VFD, Second Display & WiFi

Environment

Operating Temperature 0°C ~ 60°C
Storage Temperature -10°C ~ 70°C
Certificate CE / ROHS / FCC

Electrical

Power Supply Input / Output AC 100V-240V, 50-60Hz, DC12V / 5A
