Bluetooth two-dimensional image barcode scanner

Multi-Purpose for Everyday Use

  • Auto Scanning Stand
  • To read 1D and 2D barcode
  • Interface: USB HID Keyboard
  • Resolution: 648 x 480 Pixels
  • Built-in Bluetooth Interface



Communication Character
Work range 10 meters
Radio Link 2.4 GHz Blue 4.0 Glass
Battery capacity 1500mAh (Lithium battery)
Charging time 4.5 Hours
Full Charge 5h (continuous reading situation)
7h (manual reading situation)
> 15 days (Stand-by-time)
Communication mode Read-time mode / Inventory mode

Electrical Characteristics

Interface USB HID Keyboard
Voltage requirement DC 5V±10%
Current consumption Max: 120mA

Optical Characteristics

Photo sensor CMOS array sensor
Sensor resolution 648 x 488 pixels
Light source white LED*1
Aim light source Red bar LED

Performance Characteristics

Decode angle Pitch angle: ±55°
Skew angle: ±55°
Tilt angle: ±180°
Min resolution 1D: 5mil
2D: 10mil
Language Multiple language
Min PCS value 30% UPC/EAN 13 (13mil)
Field of view 34° (H) x 26° (V)
Identification 1D: UPC/EAN, Code 39, Code 128, Code 11, Matrix 2 of 5, Codabar, Code 93, MSI, GS1 Databar
2D: PDF417, Data Matrix, QR Code

Physical Characteristics

Dimensions 97mm x 67mm x 165mm (L x W x H)
Weight 122.8g

Environmental Characteristics

Temp Operation: -20° to 60°C / -4° to 140°F
Storage: -40° to 80°C / -40° to 176°F
Humidity Operation: 5 – 90%
Storage: 5 – 90%
Shock drop test 1.2m drop onto concrete surface
Ambient Light Fluorescent light 4000 lx max, direct sun light 80,000 lx max, white light 4000 lx max


Electrical Safety UL 60950, EN/IEC 60950
EMI/RFI FCC Part 15 Class B, EN 55024/CISPR 22
Environmental RoHS

Depth of field

Code 39UPC/EAN
Data Matrix
Resolution(mm)    Depth of field(mm)
5.0 mil                   50mm–120mm
15.0 mil                 40mm–250mm
15.0 mil                 40mm–250mm
10.0 mil                 40mm–210mm
