SSK-200/300

Self Service Kiosk

Slim and Powerful

Self-Service Kiosk is specialized machine designed and built for your customers to transact with your services without any staff presence. SSK-200 Self-Services Kiosk can be automated such as ticket selling, food ordering, bill payment or others.

Most clients deploy our kiosks to extend their customer service hours to 24×7 with low support cost, expand sales points at High Traffic Areas to increase customers satisfaction and this may help to boost sales or revenue by catering to customers who prefer self-service.

Description

General

Model SSK-200 SSK-300
Touch 21.5 inch Flat Capacitive Touch Panel 32 inch Flat Capacitive Touch Panel
Display 21.5 inch TFT LED 32 inch TFT LED
Scanner 2D
Printer 80mm Thermal Printer
Size 775 x 380 x 36mm 1000 x 500 x 35mm
Resolution 1920 x 1080 (max)
Display Angle 21.5 inch 250 cd/m2 32 inch 300 cd/m2
View Angle 88/88/88/88 (Left/Right/Up/Bottom)
Color 16.7M
Response time 12 ms
Display Life 4000 Hours
Environment Working Temperature : 0°C ~ 50°C

X86

Chips Bay Trail-D
Intel Intel Celeron J1900 Quad Core 2.0GHz
Memory 4GB DDR3L-1333MHz
Storage 64 / 128GB SSD
Graphic Card HD Graphics
Interface External : 4xUSB, 1xRJ45 LAN, 1xVGA, 1xRS232, 1xMIC, 1xDC2.5 in (12V)



Internal : 5xUSB, 1xVGA, 1xLPT, 5xRS232, 1xPS/2, 1xLVDS

OS Windows 7, Windows 8, Windows 8.1, Windows 10 and Linux
Environment Working Temperature : -10°C ~ 60°C
Storage Temperature : -20°C ~ 70°C

Android

CPU RK3288 MAX 1.8GHz
RAM 2GB DDR3
ROM 8GBEMMC, upgradable to 32GB
TF Card Max. 32GB
Video Output Support LVBDS, EDP
Interface External : 4xUSB, 1xRJ45 LAN, 1xRS232, 1xTF Card, 1xSIM Card, 1xDC2.5 in (12V)



Internal : 1xSPK, 1xWiFi IPEX, 1x3G/4G, 6xRS232, 1xLVDS, 1xEDP, 1xGPS, 1xMIC

OS Android 5.1.1 / Android 7.1.1
Environment Working Temperature : -10°C ~ 60°C
Storage Temperature : -20°C ~ 70°C

2D Scanner

Image Sensor CMOS
Resolution 752×480 CMOS
Light LED Light
Decoding Capability (1D) UPC-A, UPC-E, EAN-13, EAN-8, ISBN/
ISSN, Code 39, Code 39, Interleaved 2 of
5, Industrial 2 of 5, Matrix 2 of 5, ITF-6/14
, Codabar, Code 128, UCC/EAN 128, AIM
128, Code 93, Code 11, MSI/Plessey, UK/
Plessey, GS1 DataBar (formerly RSS)
variants
Decoding Capability (2D) PDF417, QR Code, (QR1/2 Micro), Data
Matrix (ECC200, ECC000, 050, 080, 100,
140)
Motion 2.5m/s
Precise 5mil
Depth EN13 : 60mm ~ 350mm (13mil)
PDF417 : 35mm ~ 115mm (6.67mil)
Code 39 : 30mm ~ 165mm (5mil)
Data Matrix : 30mm ~ 115mm (10mil)
QR Code : 35mm ~ 115mm (15mil)

Thermal Printer

Type 80mm Thermal Printer
Printing Direct Thermal
Paper Easy Paper Loading
Cutter Full or Partial Cut
Resolution 8 dot/mm
Thickness 60 ~120um
Speed 170mm/sec
Paper Width 79.5±0.5mm
Paper Diameter 80mm
Support Barcode EAN, UPC, JAN, Code 39, Code 128, ITF,
Codabar, QR Code
Sensor Paper near end sensor
Interface USB
Power DC24V / 2A
Life Printer : 150km, Cutter : 1 million
